Home /Products/Kitchen Freeze Dryer/Wholesale Freeze Dried Industrial Fruit Fruit Vacuum Dryer Freeze Dryer Price Food Freeze Dryer

Wholesale Freeze Dried Industrial Fruit Fruit Vacuum Dryer Freeze Dryer Price Food Freeze Dryer

1 Set
MOQ
$5,000.00(>=1 Sets)
Price
Wholesale Freeze Dried Industrial Fruit Fruit Vacuum Dryer Freeze Dryer Price Food Freeze Dryer
Features Gallery Product Description Request A Quote
Features
Specifications
Applicable Industries: Manufacturing Plant, Food & Beverage Factory
Showroom Location: None
Video Outgoing-inspection: Provided
Machinery Test Report: Provided
Marketing Type: Hot Product 2021
Warranty Of Core Components: 1 Year
Core Components: Motor
Condition: New
Type: Vacuum Freeze Dryer
Voltage: 220V/380V/440V
Power: 120kw
Weight: 16 KG
Dimension(L*W*H): 7500x2300x3200mm
Warranty: 1 Year
Freeze Drying Area: 31.68m2
Application: Fruits, Vegetables, Food And Chinese Medicinal Materials
Temperature Range: RT~120
Capacity: 300KG
MOQ: 1 Set
After Warranty Service: Video Technical Support
Basic Infomation
Payment & Shipping Terms
Packaging Details: packaging: wooden case lined with plastics or as customers'demands.
Supply Ability: 200 Set/Sets per Month
Product Description
Product Description
LGF-30 is used for freeze-drying more than 20 types of food such as meat, vegetables, fruits, aquatic products, beans, beverages, soups, health products, etc. Its products meet the requirements of naturalness, nutrition and convenience.
The LGF series is used for freeze-drying of more than 20 types of food such as meat, vegetables, fruits, aquatic products, beans, beverages, soups, health products, etc. Its products meet the requirements of naturalness, nutrition and convenience.

Main technical advantages

●Pre-freezing and drying the split structure at the same time improves the freeze-drying efficiency and shortens the freeze-drying time. ● Aerospace grade aluminum alloy partition material, double-sided radiant heating, emissivity above 90%, and good temperature uniformity. ● Efficient mixed refrigerant carrier medium, lower freezing point and higher boiling point, high heat exchange efficiency and long service life. ● The drying curve optimization control algorithm can control the product heating rate and vacuum value during the drying stage. ●Professional gas diversion design and control technology, strong water catching capacity and high drying efficiency. ● The tray is stamped and formed by aviation anti-rust aluminum alloy, and has a high heat absorption rate after special surface treatment. Each drying chamber is equipped with 2 sets of trays. ● Industrial-grade embedded touch screen + dedicated SH-HPSC-III modular controller, the system is stable and reliable, and the control accuracy is high. ● The professionally designed FD-MANAGER control system can save multiple sets of process recipes, and at the same time, the process can be adjusted in real time during the drying process to improve the process optimization rate. ● Flexible manual + automatic control mode, manual for exploring the process, automatically for mass production. ● Precise sensor calibration function to ensure the accuracy of long-term use process parameters. ● User level and password can be set, decentralized operation management. ● Optional powerful LYO-MEGA host computer control system, which can record and save operating data, curves and alarm records for up to ten years to improve the traceability of the product; at the same time, it is convenient for observation, operation and fault diagnosis. ● Non-standard customization can be made according to user needs.
Specification
Model
Unit
LGF-15
LGF-20
LGF-30
LGF-50
LGF-100
LGF-200
Freeze Drying Area
m2
16.2
20.6
31.68
52.92
105.84
209.52
Loading Capacity
KG
150
200
300
500
1000
2000
Shelf Number
layer
9+1
8+1
8+1
9+1
18+1
18+1
Shelf Size
mm
1200*1500*15
1200*2100*15
1200*3000*15
4900*1200*15
4900*1200*15
9700*1200*15
Shelf Spacing
mm
80
80
80
80
80
80
Temp Control Range
℃
Room temp ~+120℃





Ice Condensing Capacity
kg/B
≥225
≥300
≥450
≥750
≥1500
≥3000
Cold Trap Temp
℃
≤-60
≤-60
≤-60
≤-50
≤-50
≤-50
Method
-
Water cooled, water temp <30℃



Final Vacuum Degree
pa
≤ 5

China
≤ 10


Installation Power
kw
50
96
120
150
230
440
Cooling Water
m3/h
30
40
60
80
160
300
Compressed Air
L/min
20
30
30
30
30
30
Dimension(L*W*H)
mm
5200*1800*3200
6200*2300*3200
7500*2300*3200
7000*8500*3200
7000*11000*3500
7200*1100*3500
Weight
t
6
10
16
29
46
95
Company Profile
SHAANXI ROCTEC TECHNOLOGY CO, LTD. as a leading manufacturer in the field of the advanced apparatus and established in 2007,Shaanxi Rotec Technology Co.,Ltd. is a comprehensive group company with independent legal personality that mainly deals with study, development, manufacture and scaled sales of the advanced chemical apparatus and the exploration of biotechnology. In detail, we manufacture the jacketed glass reactor (double-layer glass reactor), UV-VIS Spectrophotometer, vacuum freeze dryer, centrifuge, autoclave, rotary evaporator etc

Since its very beginning of establishment, our employee has always been pursuing the spirit of "dedication , reality, competition and struggle" and supplying the well-content products service for the laboratory apparatuses, furniture, reagent, overall design and fitting-out works needed from the state-grade scientific institutes, pharmaceutical factory and colleges and universities' testing laboratories.

Our strict execution of the standard of the manufacturing technical and establishment of complete the quality management system ensure its reliable quality and strong footing in a market of so many areas and countries at home and abroad .

Looking forward to the future, we will further strength the concept of quality and service to acclimatize our self to the
scientific and technological progress with each passing day. Pengzhan Technoloy - Faithfully serve you forever!
Certifications
Packing & Delivery
FAQ
1. Are you trading company or manufacturer ?
We are factory.

2. How long is your delivery time?
Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to
quantity.

3.What is your terms of payment ?
For the beginning business, we hope 100% TT payment in advance.
If you have another question, pls feel free to contact us.

4. How to choose the suitable equipment?
Tell us your requirements, our professional sales will introduce you the most suitable model.
